주요특징 및 사양　　　
  • 1 or 2 channels
  • 1 μHz – 330 MHz pulse with variable rise/fall time

  • 1 μHz – 500 MHz sine waveform outputs

  • Precise digital noise: crest factor(peak/RMS) selectable: 3.1,4.8, 6.0, 7.0

  • Noise repetition: 20 days

  • Pulse, sine, square, ramp, noise and arbitrary waveforms

  • Triggerable

  • FM, AM, PM, FSK, PWM modulation capability

  • Full control of all pulse parameters(rise/fall/width, etc.)

  • Differential outputs

  • Ideal and arbitrary bit shaped pattern up to 330 Mbit/s(Option 330) and 660Mbit/s(Option 660)

  • Two, Three or Four level signals

  • PRBS up to 231

  • 4Mbit Pattern( 1-Channel Model), 2Mbit pattern/ch(2-Channel Model)

  • Integration in Matlab, Keysight 33503A BenchLink Waveform Builder Pro
